Rotations, scaling, and transformations modify the sample point before it is evaluated.
The rectangle below shows lines representing the distance (red being negative). Instead, the correct way to do this is to calculate the inside and outside distance and cap them so they don’t flip signs. This generates incorrect distances inside the shape. It would be naive to calculate those two values and then take the length of the resulting vector. Just take the absolute value of the distance to one of the edges or abs(T – sample_point.x).
It’s easy to determine the distance from an infinite line with some thickness (T) centered at (0,0).
Rectangles are a little more complicated, but has a handy walkthrough of the concept. How are SDFs defined? A circle is easy to define as it is the length of the vector to the center minus the circle’s radius. Freetype even merged an SDF renderer written by back in 2020. GLyphy is an SDF-based text renderer that uses OpenGL ES2 as a shader, as discussed at Linux conf in 2014. Most modern computers are extraordinarily good at calculating the same thing thousands of times with slightly different parameters, often using the GPU. So, why use this over a more traditional vector approach? The advantage is that the shape is represented by a single formula calculated at many points. By increasing the size of the grid, you can get better approximations of the actual shape of the SDF. Negative values mean the pixel is colored in as the center of the pixel is inside the shape. If the distance is greater than the size of the grid cell, the pixel is not colored in. The naive technique for rendering is to create a grid and calculate the distance at each point in the grid. of has a beautiful demo on two-dimensional SDFs that covers the basics. Additionally, it is helpful for font rendering in specific scenarios. SDFs in 2DĪ signed distance function in 2D is more straightforward to reason about so we’ll cover it first. First, we’ll discuss SDFs in 2D and then jump to 3D. A signed distance field (also SDF) is just a voxel grid where the SDF is sampled at each point on the grid. That’s precisely what a signed distance function (SDF) is.
What if instead of defining a mesh as a series of vertices and edges in a 3D space, you could describe it as a single function? The easiest function would return the signed distance to the closest point (negative meaning you were inside the object).
